| Type | XY-21(r) 160x320 | XY-21(r) 250x720 | XY-21(r) 360x1120 | XY-21(r) 450x1400 | XY-21(r) 550x1650 | XY-21(r) 610x1730 | XY-21(r) 710x2130 | XY-21(r) 810x2430 | XY-21(r) 860x2500 |
| Roll diameter(mm) | 160 | 252 | 360 | 450 | 550 | 610 | 710 | 810 | 860 |
| Working lengh of roll(mm) | 320 | 720 | 1120 | 1400 | 1650 | 1730 | 2130 | 2430 | 2500 |
| Speed ratio of roll | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 1:1 | 0.5-1 Adjustable |
| Middle-roll linear speed(m/min) | 7.79 | 1.2-12 | 3-20.2 | 2.5-24.8 | 2-18.7 | 4-36 | 2-20 | 2-20 | 3-30 |
| Adjusting nip range(mm) | 0-4.5 | 0-6 | 0-10 | 0-10 | 0-12 | 0-15 | 0.5-25 | 0.5-25 | 0-30 |
| Min calendaring product thickness(mm) | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.2 | 0.5 | 0.5 | 0.5 |
| Calendaring product width(mm) | 250 | 580 | 920 | 1250 | 1600 | 1500 | 1850 | 2150 | 2200 |
| Motor power(kw) | 5.5 | 15 | 37 | 45 | 75 | 90 | 110 | 160 | 132kwx2 |
| Overall dimensions(mm) | 2200x530x1470 | 3950x1110x1590 | 5400x1542x1681 | 7013x1595x2446 | 7200x1760x2760 | 5987x1860x2988 | 8150x3760x3630 | 8690x3139x4270 | 12000x3200x4050 |
| About weight(t) | about1.2 | about5 | about11.5 | about14 | about24 | about30 | about49 | about62 | about85 |
